Multilayer Penetrating Belt Dryer

Applications DWC multilayer penetrating belt dryer is suitable for drying of sheet type, stripe type, and granular materials, which is widely applied in the fields of food, agricultural products, dehydrated vegetables, herbs, seafood, native products, feed and chemical raw materials. FeaturesThe hot gas flow passes through the belt and material layers from bottom to top, ensuring uniform and full heat transfer. The material is uniformly distributed on the belt, and the thickness of material layer can be adjusted.    Technical Specifications of Multilayer Penetrating Belt Dryer Model DWC-20 DWC-25 DWC-32 DWC-36 DWC-48 DWC-60 DWC-80 Spreading thickness(m2) 20 25 32 36 48 60 80 Steam pressure (Mpa) 0.4~0.7 Steam consumption (Kg/h) 150-300 180-375 240-480 270-540 360-720 450-900 600-1200 Drying cycle(min) 20-200 60-600 100-1000 Evaporation capacity(Kg/h) 100-200 125-250 160-320 180-360 300-480…
