High power piezo disc for ultrasonic transducer OD28x1MHz

Piezoelectric ceramic disc    Quick shipments High power low dielectric loss wrapped arround electrode available Application: ultrasonic slimming transducer,  Material:  PZT-82 (hard PZT, equal to P-8) or PBaS-4(hard PZT, high dielectric constant 1900) This material range is used in high power applications, even though its piezoelectric activity level is slightly lower than PZT-4 series types. With an extremely high mechanical quality factor and extremely low loss factor, PZT-82 series piezo material have the ultimate power handling capability.  Technical data: Dimensions:  diameter 28mm, thickness 2mm according to frequency 1MHz  Thickness Frequency(Ft) 1MHz ± 5% Statics Capacity (pF) 2500pF ± 12.5% Dielectric loss(tgδ)(1v,KHz) ≤0.3% Re…
